Wall & Ceiling Panelling

You are not a fan of bare walls or ceilings and you are looking for that certain something for an unforgettable room feeling?

With perforated panels made of MDF, CELLON® or OAK PLYWOOD, your room becomes an experience. Whether with or without LED lighting, your visitors will be thrilled.

  • available in 3 materials, 4 thicknesses and 3,000 colours or with an oak look
  • warm and comfortable material made of wood that is nice to touch
  • easily expandable to an illuminated wall or acoustic solution
  • individual because of precise laser cutting - your drawing becomes the product
    • Slider 1
    • Slider 4
    • Slider 3
    • Slider 2

    02.Material

    MDF board is a wood-based material made of finely fibrillated softwood, which is pressed into a board product that is equally homogeneous in the longitudinal and transverse directions. Due to its dimensional stability, MDF board is ideal for interior design elements.

    The MDF board is the proven solution for all interior applications. Due to the neutral substrate, the MDF board is excellently suited for coating in the desired colour shade. The homogeneous surface looks noble and yet natural. The thickness of up to 30 mm emphasises the three-dimensionality to the maximum.

    Thickness: 10 mm 19 mm 30 mm

    Formats

    The raw panels are project-specifically cut to the desired dimensions using laser technology (including drill holes). You choose the width (x) and the length (y) of the panels individually. Do you want round cuts or additional cut-outs? Simply draw them in your DXF plan and they will be manufactured to size.

    Please consider the following raw panel formats for waste optimisation:

    perforated panels
    MDF design

    raw width

    raw length

    2050 mm

    4050 mm

    plain panels
    MDF classic

    raw width

    raw length

    1300 mm

    4050 mm

    The OAK PLYWOOD panel consists of individual layers of wood, which are glued and pressed crosswise to their fibre direction. This reduces directional properties such as swelling and shrinkage. OAK PLYWOOD brings a natural wood look into the interior.

    The beautiful, rustic oak surface is protected from scratches and dirt with an invisible coating. The edges are black due to the laser cutting, which makes the wood surface stand out more and increases the depth effect. This combination of dark edges and oak brings that little extra to any room.

    Thickness: 18 mm

    Formats

    The raw panels are project-specifically cut to the desired dimensions using laser technology (including drill holes). You choose the width (x) and the length (y) of the panels individually. Do you want round cuts or additional cut-outs? Simply draw them in your DXF plan and they will be manufactured to size.

    Please consider the following raw panel formats for waste optimisation:

    perforated panels
    EICHENSPERRHOLZ design

    raw width

    raw length

    1500 mm

    3000 mm

    plain panels
    EICHENSPERRHOLZ classic

    raw width

    raw length

    1300 mm

    3000 mm

    Our CELLON® panel is a high-pressure laminate panel (HPL Compact or solid core panel) consisting of 70% cellulose webs and 30% phenolic resin. The extremely weather and frost-resistant material is ideal for outdoor applications.

    The HPL panel convinces with absolute moisture resistance and minimal expansion. In contrast to conventional HPL panels, CELLON® is characterized not only by the variety of shapes and colors available, but above all by its natural appearance. The colour is applied directly to the resin and thus the top layer, which means that the sterile resin surface does not stand out, but rather the selected color concept is ideally emphasized.

    Thickness: 8 mm 10 mm

    Formats

    The raw panels are project-specifically cut to the desired dimensions using laser technology (including drill holes). You choose the width (x) and the length (y) of the panels individually. Do you want round cuts or additional cut-outs? Simply draw them in your DXF plan and they will be manufactured to size.

    Please consider the following raw panel formats for waste optimisation:

    perforated panels
    CELLON® design

    raw width

    raw length

    1200 mm

    1280 mm
    1500 mm
    1800 mm

    2400 mm
    3000 mm*
    3600 mm
    3600 mm

    plain panels
    CELLON® classic

    raw width

    raw length

    1200 mm

    1280 mm
    900 mm

    2400 mm
    3000 mm*
    3600 mm

    *Only this format is also available with a decor surface in stone or wood look.

    03.Colours and Surfaces

    Choose your wall or ceiling element from over 3,000 RAL, NCS S or colour with special metallic effect. For a natural appearance, the panels are also available in oak plywood with elegant black edges. The cut-outs can be covered with felt, available in 44 colours.

    Farbfächer
    beschichtet design (MDF & HPL)_EN
    decor design (Sperrholz)_EN
    A-Kollektion

    04.Design

    Completely customize your room and choose from one of our 100+ designs or create your very own pattern. We are happy to adapt our templates to your needs, thanks to laser cutting, individuality is guaranteed.

    to Collection

    05.Construction Solutions

    Wall or ceiling claddings made of perforated panels bring that certain something into your room and are easy to install The panels can either be fixed directly to an existing wall or to a construction frame. The perforation cut-outs can be backed with felt or a transparent film for LED lighting.

    Wall & Ceiling Claddingsd with Felt
    Wall & Ceiling Claddingsd with LED

    Further information on construction and installation is described in our data sheet.

    to Data Sheet

    06.Project Procedure

    In addition to supplying the panels with the desired felt or translucent film, we will also be happy to advise you on the choice of design and material colours. The substructure and on-site installation, as well as any LED lighting, is carried out by the qualified craftsman and the specialists. We deliver the material to the installing company, which makes an overall offer to the contractor.

    Prozess m. Filz und Transluzente Folie_EN

    Summary:

    Designing Rooms Smartly. Open rooms are a trend. This is good, because they are giving us a feeling of freedom and are often light. But with this trend, a smart floor plan becomes inevitable. With our flexible-to-use room dividers, you can keep the good qualities of your room and take care of the necessary privacy. More than that. A room divider or a wall cladding by Bruag can be an eye catcher in your interior design.

    Let yourself be inspired by projects that have already been implemented or go on to the technical information sheet for partitions and wall claddings, the brochure for all indoor applications or our perforation collection with design templates. In addition to the almost unlimited variety of shapes, there is also a very large selection of colour options.
